NVR308-32R-B
NVR308-32R-B
NVR308-32R-B Uzman Bayi Satış Ekibi, Profesyonel Teknik Destek Hizmeti ile DESS Elektronik'te en iyi fiyat garantisi ile...
Model
NVR308-32R-B
NVR308-64R-B
Video/Audio Input
IP Video Input
32-ch
64-ch
Two-way Audio Input
1-ch, RCA
Network
Incoming Bandwidth
320Mbps
Outgoing Bandwidth
320Mbps
Remote Users
128
Protocols
IPV4, IPV6, SNMP,P2P, UPnP, NTP, DHCP, PPPoE, HTTP, SMTP, TCP/IP, RTSP
Video/Audio Output
HDMI/VGA Output
HDMI1/VGA:
1920x1080p /60Hz, 1920x1080p /50Hz, 1600x1200 /60Hz, 1280x1024 /60Hz, 1280x720 /60Hz, 1024x768 /60Hz
HDMI2:
4K (3840x2160) /60Hz, 4K (3840x2160) /30Hz, 1920x1080p /60Hz, 1920x1080p /50Hz, 1600x1200 /60Hz, 1280x1024 /60Hz, 1280x720 /60Hz, 1024x768 /60Hz
CVBS Output
1-ch, BNC
Recording Resolution
12MP/8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF
Audio Output
1-ch, RCA
Synchronous Playback
16-ch
Corridor Mode Screen
3/4/5/7/9/10/12/16/32
Decoding
Decoding format
Ultra 265, H.265, H.264
Live view/ Playback
12MP/8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF
Capability
3 x 12MP@25, 4 x 4K@30, 8 x 4MP@30, 16 x 1080P@30, 32 x 960P@25, 36 x 720P@30, 64 x D1
Hard Disk
SATA
8 SATA interfaces
Capacity
Up to 10TB for each HDD
eSATA
1 eSATA interface
Smart
VCA Detection
Face detection, Intrusion detection, Cross line detection, Audio detection, Defocus detection, Scene change detection, Auto tracking
VCA Search
Face search, Behavior search
Statistical Analysis
People counting
Disk Array
Array Type
RAID 0, 1, 5, 6, 10
External Interface
Network Interface
2 RJ45 10M/100M/1000M self-adaptive Ethernet Interfaces
Serial Interface
1 x RS232, 1 x RS485
USB Interface
Rear panel: 2 x USB2.0, 1 x USB3.0
Alarm In
16-ch
Alarm Out
4-ch
General
Power Supply
100 ~ 240 VAC
Power Consumption: ≤ 20 W( without HDD )
Working Environment
-10°C ~ + 55°C ( +14°F ~ +131°F ), Humidity ≤ 90% RH(non-condensing)
Dimensions(W×D×H)
442mm ×531mm ×86mm (17.4" × 20.9"×3.4")
Weight ( without HDD )
≤ 5.13 Kg (11.31 lb )
Certification
CE, FCC
| Model | NVR308-32R-B | NVR308-64R-B |
| Video/Audio Input | ||
| IP Video Input | 32-ch | 64-ch |
| Two-way Audio Input | 1-ch, RCA | |
| Network | ||
| Incoming Bandwidth | 320Mbps | |
| Outgoing Bandwidth | 320Mbps | |
| Remote Users | 128 | |
| Protocols | IPV4, IPV6, SNMP,P2P, UPnP, NTP, DHCP, PPPoE, HTTP, SMTP, TCP/IP, RTSP | |
| Video/Audio Output | ||
| HDMI/VGA Output | HDMI1/VGA: 1920x1080p /60Hz, 1920x1080p /50Hz, 1600x1200 /60Hz, 1280x1024 /60Hz, 1280x720 /60Hz, 1024x768 /60Hz HDMI2: 4K (3840x2160) /60Hz, 4K (3840x2160) /30Hz, 1920x1080p /60Hz, 1920x1080p /50Hz, 1600x1200 /60Hz, 1280x1024 /60Hz, 1280x720 /60Hz, 1024x768 /60Hz |
|
| CVBS Output | 1-ch, BNC | |
| Recording Resolution | 12MP/8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF | |
| Audio Output | 1-ch, RCA | |
| Synchronous Playback | 16-ch | |
| Corridor Mode Screen | 3/4/5/7/9/10/12/16/32 | |
| Decoding | ||
| Decoding format | Ultra 265, H.265, H.264 | |
| Live view/ Playback | 12MP/8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF | |
| Capability | 3 x 12MP@25, 4 x 4K@30, 8 x 4MP@30, 16 x 1080P@30, 32 x 960P@25, 36 x 720P@30, 64 x D1 | |
| Hard Disk | ||
| SATA | 8 SATA interfaces | |
| Capacity | Up to 10TB for each HDD | |
| eSATA | 1 eSATA interface | |
| Smart | ||
| VCA Detection | Face detection, Intrusion detection, Cross line detection, Audio detection, Defocus detection, Scene change detection, Auto tracking | |
| VCA Search | Face search, Behavior search | |
| Statistical Analysis | People counting | |
| Disk Array | ||
| Array Type | RAID 0, 1, 5, 6, 10 | |
| External Interface | ||
| Network Interface | 2 RJ45 10M/100M/1000M self-adaptive Ethernet Interfaces | |
| Serial Interface | 1 x RS232, 1 x RS485 | |
| USB Interface | Rear panel: 2 x USB2.0, 1 x USB3.0 | |
| Alarm In | 16-ch | |
| Alarm Out | 4-ch | |
| General | ||
| Power Supply | 100 ~ 240 VAC Power Consumption: ≤ 20 W( without HDD ) |
|
| Working Environment | -10°C ~ + 55°C ( +14°F ~ +131°F ), Humidity ≤ 90% RH(non-condensing) | |
| Dimensions(W×D×H) | 442mm ×531mm ×86mm (17.4" × 20.9"×3.4") | |
| Weight ( without HDD ) | ≤ 5.13 Kg (11.31 lb ) | |
| Certification | CE, FCC | |
| Kanal Sayısı | : | 32 Kanal |
