Technical Specifications

General

Standards
 • IEEE 802.3 10BASE-T Ethernet (twisted-pair copper)
 • ANSI/IEEE 802.3 NWay auto-negotiation
 • IEEE 802.3x flow control
 • IEEE 802.3u 100BASE-TX Fast Ethernet (twisted-pair copper)

Ports
 • 8 10/100 Mbps PoE ports

Switching Fabric
 • 1.6 Gbps switching fabric

Data Transfer Rates
 • Ethernet
    • 10 Mbps (half duplex)
    • 20 Mbps (full duplex)
 • Fast Ethernet
    • 100 Mbps (half duplex)
    • 200 Mbps (full duplex)

Media Interface Exchange
 • Auto MDI/MDIX adjustment for all ports

Network Cables
 • 10BASE-T
    • UTP CAT 3/4/5/5e (100 m max.)
    • EIA/TIA-586 100-ohm STP (100 m max.)
 • 100BASE-TX
    • UTP CAT 5/5e (100 m max.)
    • EIA/TIA-568 100-ohm STP (100 m max.)

LED Indicators
 • Per port:
    • Link/Activity
    • PoE Status
 • Per device:
    • Power
    • PoE Max 1
    • PoE Max 2

Transmission Method
 • Store-and-forward

MAC Address Table
 • 2K entries per device

Packet Filtering/Forwarding Rates
 • Ethernet: 14,880 pps per port
 • Fast Ethernet: 148,800 pps per port

RAM Buffer
 • 96 KB per device

Physical & Environmental

Dimensions
 • 11.02” x 7.05” x 1.75” (280mm x 179mm x 44.5mm)

Heat Dissipation
 • Standby:
    • 22.67 BTU/h
 • Maximum:
    • 486.7 BTU/h

Power Input
 • 100 to 240 VAC, 50/60 Hz, Internal Universal Power Supply

Power Consumption
 • Standby:
    • 6.9W
 • Maximum:
    • 146W

Weight
 • 3.6 lbs (1.65 Kg)

Temperature
 • Operating: 32 to 104˚ F (0 to 40˚ C)
 • Storage: -40 to 158˚ F (-40 to 70˚ C)

Humidity
 • Operating: 5% to 95% RH non-condensing
 • Storage: 5% to 95% RH non-condensing

Certifications
 • FCC Class B
 • CE
 • RoHS
 • cUL

Power over Ethernet

PoE capable ports
 • Ports 1 - 8

PoE standard
 • IEEE 802.3af and IEEE 802.3at

PoE power budget
 • 140W total
    • Ports 1-4: 70W
    • Ports 5-8: 70W

Warranty Information

Warranty
• Limited Lifetime
